Jinde Non-magnetic mobile cart

This non-magnetic wheelchair is constructed entirely of non-ferrous materials. Specifically designed for
use in and around the MRI suite. All materials are non-magnetic.
Introduction
This non-magnetic wheelchair is constructed entirely of non-ferrous materials. Specifically designed for use in and around the MRI suite.
Colors can match between black, red & black and bright yellow, purple (It is the whole world's only all-plastic foldable lightweight wheelchair).

Quantity:
  • Jinde Non-magnetic mobile cart
  • jinde

Jinde Non-magnetic mobile cart


Applications

The main material of this product is high-strength aluminum alloy, overall free magnetic, applicable for MRI environment in hospitals in all districts.



Characteristics

This non-magnetic mobile cart is mainly constructed of high-strength aluminum alloy, which consists of aluminum body, restraining straps and mattress. It has the following characteristics :( picture as below)

1. Foam-padded mattress, so that the patient feel comfortable;

2. Backrest can be adjusted for some angles to meet all types of patient needs;

3. Guardrails to ensure patient safety;

4. The cart is designed with high height structure, convenient for moving on floor and lifting.







Aluminum   Stainless steel  PU leather + sponge     High strength nylon



Specifications

Ø  Maximum external dimensions(LxWxH)..........................1920×590×650mm

Ø  Size of top surface (LxW).........................................................1920×590mm

Ø  Maximum inclination of backrest .............................................................60º

Ø  Wheelbase..........................................................................................1320mm

Ø  Net Weight:..............................................................................................23Kg

Ø  Load capacity:.......................................................................................195Kg



instruction of use

1. Lift the backrest a little bit according to the patient’s need. Firstly press the adjusting handle and lift the backrest to a proper angle, then tilt it up and down to have it locked in place;

2. In case of needing to lift the cart,

3. On flat ground, hold the handles and can easily transporting patients.



V. Matters need attention

1. To ensure safety, when transporting the patient, please fold up guardrails at both sides.

2. When moving the patient out of the stretcher, remember to lock the casters to ensure the safety;

3. Better lubricate all movable knobs and rotating joints by oil after long time use.

4. Make sure no strings or similar stuff entangle the axle of the casters so as to avoid jam;

5. In case the stretcher is contaminated, clean the frame and mattress with a wet towel first and then use 75 concentration of alcohol or colorless thimerosal for disinfection;

6. The manufacturer will repair, replace parts or product within one year from date of Ex works against malfunction or manufacturing defaults on the condition of normal storage, transportation and usage;

7. This product must not to be packed under heavy cargo during transport. Well-packed finished goods should be stored at airy and no rainy places with a relative humidity less than 85% RH.  Do not store it together with toxic and harmful objects.
